Cast Iron Horizontal Lift Check Valve, Flanged Ends, PN-16 | AV253
Features
Testing Standard
BS EN 12266-Part 1
Pressure / Class Rating
PN-16
Body Material Cum Standard
Cast Iron (IBR 86 to 93 Gr. A)
Product Description
Bolted Cover
Type of Seat
Renewable Seat
Type of Disc
Renewable Disc
Trim
13% Cr. (SS 410)
End Details
Flanged Drilling as per BS-10 Table-H Raised Face (PN-16)
Test Pressure
Body: 24 kg/cm² (Hyd.), Seat & Back Seat : 17.6 kg/cm²
Max. Working Pressure
13 kg/cm² (Steam)
Max. Working Temperature
220°C
Notes
Test Certificate in Form III-C as per IBR is furnished with every supply.
Description
IBR (Indian Boiler Regulation) valves are specialized industrial valves designed to meet the stringent safety and quality standards set by the Indian Boiler Regulation Act. IBR valves are primarily used in industries where boilers and pressure vessels are employed. This includes industries such as power generation, petrochemicals, textiles, pharmaceuticals, food processing, and more. IBR valves come in various types, including gate valves, globe valves, check valves, safety valves, and blowdown valves, among others. Each type serves a specific function in controlling the flow, pressure, or safety of the fluid or gas within the boiler or pressure vessel system.
